設備特點 Equipment Features

1、全自動修磨機為三軸伺服聯動，以極坐標的形式實現空間打磨曲線，產品精度更高；

With X/Y/Z three-axis servo motor linkage. Spatial curve grinding is achieved in the form of polar coordinates. High grinding accuracy.

2、設備全自動控制，避免人為干預，安全、高效；

Fully automatic control. Avoid manual intervention. Safe and efficient.

3、設備配備激光掃描儀，可快速掃描輪胎輪廓并精準建模；

Equipped with a laser scanner. Can accurately scan the tread contour and model the profile.

4、設備具有輪輞自動定中功能，可自動調整輪輞間距以適應不同寬度輪胎；

Equipped with automatic determination which can automatically adjust the rim spacing to accommodate different width tires.

5、設備標配三級輪輞，相比傳統輪輞能夠匹配更多規格輪胎；

Equipped with three-stage rims as standard. Match more specifications of tires compared with the traditional tire rim.

6、設備標配胎側清掃模塊，可對胎側進行打磨、清掃；

With tire sidewall cleaning device as standard. Can buffing and cleaning on the sidewall.

7、設備標配隔音房，將工作噪音降至最低。

With soundproof room as standard. Minimize the working noise.

技術參數technical parameter

輪輞規格Rim Size              10’’-24’’inch

輪胎寬度 Tread Width          130-400mm

子口寬度 Tire Bead Width       75-380mm

輪胎直徑Tire Diameter          400-960mm

進刀效率Tool Feed Efficiency      0.01mm/times≤ψ≤0.45mm/times

功率Power                    30.1 KW

外形尺寸Dimensions            3270×2750×2750 mm

重量Weight                   3500 Kg
